3G Personal Mini Tracker
  • Overview
  • Specification


The MT-900C (personal mini tracker)is a portable compact tracking device for personal safety and asset monitoting. It combines high sensitivity GPS and 3G wireless interface to perform the powerful security application. Base on Quad-band GSM/GPRS 850/900/1800/1900 MHz, WCDMA / UMTS/HSPA network, and GPS satellite positioning system, the MT-900C (persoanl mini tracker) can track far-way objects by short message or internet. It can be used for child protection, anti-kidnapping, vehicle tracking, pets go out tracking, panic assistant for the aged, and much more.


  • 3.75G WCDMA/UMTS/HSPA communications
  • Available Quad band GSM/GPRS/EDGE    850/900/1800/1900 MHz
  • GPS 50 channels all-in-view tracking with AGPS  supported.
  • GPS high sensitivity -162 dBm.
  • Real time dynamic reporting based on time interval.
  • Data logger capability built in with 4Mega bytes  flash memory to record time stamp, position and event status.
  • 3D G-sensor to report motion sensing, accident    from ±4G.
  • Remote command control by SMS or  GPRS/EDGE/3G network (supporting TCP/UDP).
  • Cell ID positioning supporting
  • Emergency call and notification, plus SMS sending  location.
  • Geo-fence capability with out of fencing notification.
  • Over speed notification capability.
  • Low battery notification capability.
  • Power management for low power consumption.
  • Surrounding audio monitoring capability.(option)
  • Mini USB for charging and data exchanging.
  • Personal service center program support.
  • Over the air(OTA) firmware update

General Specification

Parameter Specification
Operating Voltage 3.4V
Operating Temperature -20℃~ +60℃
Storage Temperature -40℃~ +85℃

Power Consumption


Normal  180mA

Idle mode < 3mA (with mobile idle)

Battery 500 mAh
USB Power Input 5V, 500mA
Battery Voltage Min:3.4V, Type:3.7V, Max:4.2V
SIM card type 1.8V, 3V
SIM card holder type Push-push type
LED status indicator Emergent Alarm/ Charge/ Power/ Mobile/ GPS
Dimension 53*37*20 mm
Weight 39g
